In the world of construction and engineering, the generation of accurate and efficient 2D drawings for large-scale reinforced structures has long been a challenging and time-consuming task. However, a groundbreaking study led by Wenming Jiang from the Huazhong University of Science and Technology and China Academy of Building Research, Beijing Glory PKPM Technology Co., Ltd, is set to revolutionize this process. Published in the journal *Developments in the Built Environment* (translated as *Advances in the Built Environment*), the research introduces a novel geometric-parametric hidden-line removal algorithm that promises to significantly enhance the efficiency and accuracy of drawing large-scale rebar components.
The study addresses a critical need in the industry, where the traditional methods of creating 2D drawings for reinforced structures have been notoriously inefficient and prone to inaccuracies. “The conventional approaches often involve complex 3D solid intersections, which are computationally expensive and time-consuming,” explains Wenming Jiang. “Our method simplifies this process by representing each bar with a lightweight ‘central axis + section parameters’ model, transforming 3D solid intersections into parameter-domain analysis.”
This innovative approach not only reduces geometric complexity but also substantially accelerates the drawing process. The algorithm employs curvature-driven adaptive triangulation to accurately extract contours of concrete components and uses a BVH-based coarse-screening and precise-detection pipeline to speed up occlusion computation. The result is a significant reduction in runtime, with the proposed method requiring only 10–30% of the runtime of the OCC algorithm, achieving efficiency gains of up to 92.16%.
The implications for the construction and energy sectors are profound. Large-scale reinforced structures, such as those found in energy infrastructure, require precise and efficient drawing processes to ensure safety and compliance. The proposed algorithm not only meets engineering drawing standards but also significantly reduces the need for manual corrections, saving time and resources. “This method provides an efficient, controllable, and scalable computational framework for automated drawing generation of large-scale rebar components,” says Jiang. “It has strong transferability to applications like bridge reinforcement, rail-transit pipelines, and other slender-structure scenarios.”
Looking ahead, the research team envisions integrating the parametric centerline-based visibility determination framework with AI models such as Random Forest, Neural Implicit Fields (NIF), and PolyDiff Model. This integration could enable more efficient and generalizable hidden-line removal and visibility prediction across complex, cross-domain scenarios, further enhancing the capabilities of the algorithm.
As the construction industry continues to evolve, the need for efficient and accurate drawing processes will only grow. This research by Wenming Jiang and his team represents a significant step forward in meeting this need, offering a solution that is not only technically robust but also commercially impactful. With the potential to streamline operations and reduce costs, this algorithm could become a game-changer in the field of construction and engineering.
